Ash Fusion Analyzer- IF2000G Series

Overview of Ash Fusion Analyzer

Uses the Latest technology in the service of the fusion temperature determinations Sylab Ash Fusion Analyzer automatically determines four critical temperatures: Deformation Temperature, Softening temperature, Hemispherical Temperature and Fluid Temperatures. It is a Fully automatic instrument for determining the Ash Fusion points by means of Image analysis. Sylab’s Ash fusion analyzer uses modern technology for monitoring, computing, and storing results and curves obtained during the test. Up to 6 samples can be analysed in each batch.

Highlights of the Ash Fusion Analyzer

  • Precisely controlled high horizontal static temperature furnace
  • Accepts six samples either cylinder, pyramid or cone
  • High Strength Four element heating furnace
  • Work tube with an integrated light for samples having low initial deformation temperatures
  • Digital over-temperature protection with high alarm relay integrated high-resolution camera which is isolated from the high-temperature area to improve camera life.
  • Capable to record the complete analysis video and digital capture of the images
  • Adjustable grid scale for each test specimen
  • Grid overlay feature for accurate comparison of sample height and width
  • All test results Comply with ASTM, CEN/TS, ISO and DIN test methods. Storage of individual sample pictures (1 deg C by 1 deg C)
  • Inbuilt CO/CO2 and CO2/H2 gas mixtures are capable of accepting premixed gases
  • Inbuilt flow meters for oxidising and reducing gas flow

Details

  • Programmable furnace temperature ranges
  • Maximum furnace temperature:1500 deg C
  • The furnace is capable to work at both oxidizing and reducing atmospheres
  • Programmable ramp rates from 1deg C to 12 deg C
  • Temperature Resolution 1 deg C
  • Specific temperature determination precision 20 deg C
  • Temperature is identified by quickly scrolling through the stored image
  • Accepts specimens having Cylinder, Pyramid and Cone shape from 3mm x 3mm to 6mm x 6mm x 19mm dimensions.
  • Direct specimen capturing without using mirrors for accurate and precise fusion temperature measurements.
  • Gases: CO/CO2 & CO2/H2 mixtures ready to use, additional features include CO, CO2 and H2 separate entries, and mixtures automatically made by the analyzer. Oxidizing atmospheres by inbuilt Air Pump (or) External Air Compressor.
  • Automatic airflow cooling for the furnace + CO/CO2/H2/Air exhaust tube to the lab hood.

AFT is available in multiple models based on the application and samples

  • IF2000G-HDC (Operating temperatures up to 1500 deg C)
  • IF2000G-HDBM (High temperature furnace with operating temperatures up to 1750 deg C)

  • Long Non porous alumina tube
  • Sliding Tray, Ceramic
  • Ceramic Exhaust tube
  • Ceramic Thermocouple Tube
  • Alumina Fusion Tray
  • Silicon Carbide Heating Element
  • Bronze Mold, AFT, Cylinder
  • Bronze Mold, AFT, Pyramid
  • Agate Mortar and Pestle
  • Ceramic bridge, 6 samples
  • Adaptor, Fusion Tube

We can offer CRMs which are compatible with our AFT, from world-renowned manufacturers. Please do contact us for further information

Gallery

Ash Fusion Analyzer- IF2000G-HDC
Ash Fusion Analyzer- IF2000G-HDC
Ash Fusion Analyzer- IF2000G-HDC
Ash Fusion Analyzer- IF2000G-HDC

Software

  • Sylab AFT software gives complete solutions for your Ash Fusion analysis.
  • Automatic sample shape identification.
  • Continuous recording of sample images.
  • Real time monitoring of the samples and test process
  • Option to replay the stored images for finding the sample characteristics against temperature raise.
  • Test protocols, as per ISO, ASTM, CEN/TS, DIN,CEN/TR and BIS test methods are included, in addition to simulated analysis features using recorded pictures of a previous analysis.
  • Automatic identification settings are included in the setup, sample shape automatic recognition and computed points are automatically set according to the selected norms.
  • Automatic and continuous high-resolution images of four melting points of each sample at different temperature intervals are set by customer preference on the computer.
  • The image capture rate can be programmable from 1 deg C per minute to 12 deg C per minute.
  • Automatic multiple images are stored on a computer in sequence including date, time and batch identified and the temperature at the point of capture.

Typical Sample Materials

Theory of Operation

During combustion of samples like Coal, Coke, Biomass and Refuse derived fuel, the remaining non-combustible material becomes ash or liquid slag. Ash Fusion Analyzers are used to determine ash cone deformation temperatures. The ash cones change shape in response to increasing heat. Temperatures are recorded for different stages in the shape changes, which, in order of increasing heat, are called : Initial deformation temperature (IT), Softening temperature (ST), Hemispherical Temperature (HT) and Fluid Temperature (FT). The behaviour of the Ash residue at high temperatures is a critical factor in selecting the suitable fuel for boilers and furnaces.

Ash Fusion temperature is measured at 4 points or stages of heating, by observation of the behaviour of triangular Pyramids, Cones, Cylinders prepared from ash when heated at a specific rate in a controlled atmosphere.

The Ash Fusion Analyzer determines the behaviour of fuel ash in combustion, gasification, liquefaction and ash utilization. The characteristics of fuel ash for its tendency to slag and foul have been traditionally related to the bulk chemistry of the ash and ash fusion temperatures. It can cause slagging or clogging problems on combustion chamber and pipe surfaces and decline heat transfer efficiency. It is said that the operating temperature should be below the fluid temperature (FT). Thus, it is necessary to study the Ash Fusion Analyzer not only theoretically, but also for practical application.

The Higher the fusion temperatures of the fuel-ash, the lower the tendency of the ash to slag in the combustion chamber of boilers.

Ash Fusion temperatures are often cited in fuel specifications for boilers, because they are believed to be a measure of the tendency of Coal Ash to form clinkers.

Technical Specifications for IF2000G-HDC

Ash Fusibility Determination Automatic
Fusion Points IT (Initial deformation Temperature),
ST (Softening Temperature),
HT (Hemisphere Temperature) &
FT (Fluid/Flow Temperature)
Maximum Samples per Analysis Up to 6 samples can be analysed in each batch.
Test Method IF2000G-HD/IF2000G-HDC complies with ISO 540, ASTM D 1857, CEN/TS 15370-1, CEN/TR 15404.
Analysis Time 3 runs per working day
Capable to Analyse Cube, Cylinder, Truncated cone and Pyramids
Analysis atmosphere Oxidizing Atmosphere/Reducing atmosphere
Sample shape identification Automatic, Pyramid, Truncated cone, Pyramid and Cylinder
Temperature range up to 1600 deg C
Temperature Ramp Rate programmable 1 deg C to 12 deg C per minute
Heating elements Silicon carbide
Operating Condition 15 deg C to 35 deg C 20% to 80%, non-condensing.
Safety Integrated CO monitor with auditory alarm, gas flow stops on alarm

Technical Specifications for IF2000G-HDBM

Ash Fusibility Determination Automatic
Fusion Points IT (Initial deformation Temperature),
ST (Softening Temperature),
HT (Hemisphere Temperature) &
FT (Fluid/Flow Temperature)
Maximum Samples per Analysis Up to 6 samples can be analysed in each batch.
Test Method IF2000G-HD/IF2000G-HDBM complies with ISO 540, ASTM D 1857, CEN/TS 15370-1, CEN/TR 15404.
Analysis Time 3 runs per working day
Capable to Analyse Cube, Cylinder, Truncated cone and Pyramids
Analysis atmosphere Oxidizing Atmosphere/Reducing atmosphere
Sample shape identification Automatic, Pyramid, Truncated cone, Pyramid and Cylinder
Temperature range up to 1800 deg C
Temperature Ramp Rate programmable 1 deg C to 12 deg C per minute
Heating elements Lanthanum Chromite
Operating Condition 15 deg C to 35 deg C 20% to 80%, non-condensing.
Safety Integrated CO monitor with auditory alarm, gas flow stops on alarm
